Description
|
Product Name
|
etonm planetary gear brushless motor 24V 120RPM long life time 12V electric dc motor
|
|
Material
|
stainless steel
|
|
Voltage
|
9-24v
|
|
speed
|
1-1500rpm
|
|
Torque
|
0.5-80kg.cm
|
|
Advantage
|
small dimension,low noise, factory price
|
|
Certification
|
CE, ROHS
|
|
Application
|
feeder, coffee machine, electric valve, humidifier, fans…
|
|
Model
|
Voltage
|
No-load speed r/min
|
No-load current mA
|
Rated speed r/min
|
Rated current mA
|
Rated torque kg.cm
|
|
ET-PGM36BL-121620
|
12VDC
|
1620
|
<0.36
|
1300
|
<1.7
|
1.0
|
|
ET-PGM36BL-121150
|
12VDC
|
1150
|
<0.36
|
920
|
<1.7
|
1.2
|
|
ET-PGM36BL-12428
|
12VDC
|
428
|
<0.36
|
360
|
<1.7
|
2.0
|
|
ET-PGM36BL-12357
|
12VDC
|
357
|
<0.36
|
285
|
<1.7
|
2.8
|
|
ET-PGM36BL-12185
|
12VDC
|
185
|
<0.36
|
148
|
<1.7
|
5.5
|
|
ET-PGM36BL-1298
|
12VDC
|
98
|
<0.36
|
78
|
<1.7
|
9.3
|
|
ET-PGM36BL-1250
|
12VDC
|
50
|
<0.36
|
40
|
<1.7
|
18
|
|
ET-PGM36BL-1236
|
12VDC
|
36
|
<0.36
|
29
|
<1.7
|
25
|
|
ET-PGM36BL-125.0
|
12VDC
|
5.0
|
<0.36
|
4.0
|
<1.7
|
60*
|
|
ET-PGM36BL-122.6
|
12VDC
|
2.6
|
<0.36
|
2.0
|
<1.7
|
60*
|
|
ET-PGM36BL-121.3
|
12VDC
|
1.3
|
<0.36
|
1.0
|
<1.7
|
60*
|
Notes: Brushless dc motor/BLDC Motor functions:
1. CW/CCW
2. PWM speed control
3. Signal feedback
4. Brake
